Digital LCR Meter
Measures inductance, capacitance and resistance accurately to improve the precision of experimental results. Suitable for electrical measurement tasks in the laboratory.
Also listed in: Education: Power supplies & measuring instruments
Specifications
- Brand
- PASCO · SE-8792
- Inductance
- 20 μH, 200 μH, 2000.0 μH, 20.0000 mH, 200.00 mH ±(0.5% rdg + 5 digits); 2000.0 mH, 20.000 H, 200.00 H, 2000.0H (DF <0.1)
- Capacitance
- 20 pF, 200 pF, 2000 pF, 20.000 nF, 200.00 nF, 2000.0 nF ±(0.5% rdg + 5 digits); 20.000 μF, 200.00 μF, 2.0000 mF, 20.00 mF (DF <0.1)
- Resistance
- 20.00 Ω, 200.00 Ω, 2.0000 kΩ, 20.000 kΩ, 200.00 kΩ, 2.0000 MΩ, 20.000 MΩ, 200.0 MΩ ±(0.5% rdg + 5 digits)
- Test Frequency
- 100 Hz, 120 Hz, 1 kHz, 10 kHz, 100 kHz
- Power
- 9 V alkaline battery (included)
- Accessories
- Test leads (2), alligator clips (2), protective holder
On request
Variants & pricing
Digital LCR Meter
SE-8792On request
