Physics equipment
Drive Unit – Wave Machine
A drive unit for running the demonstration wave machine continuously at a smoothly adjustable frequency. The crank disc and connecting rod are coupled by a magnetic engagement mechanism, and the stroke can be set to 10 mm or 32 mm over a frequency range of about 275 mHz to 2.85 Hz. It runs from a 12 V AC plug-in power supply (500 mA), measures approximately 60 x 90 x 160 mm without its base and weighs about 640 g including the power supply.
Specifications
- Brand
- 3B Scientific · 1021156
- Stroke
- 10 mm or 32 mm
- Frequency
- 275 mHz – 2.85 Hz approx.
- Power supply
- Plug-in power supply, 12 V AC, 500 mA
- Dimensions
- 60 mm x 90 mm x 160 mm approx. (without base)
- Weight
- 640 g approx., (including plug-in power supply)
from
€462.00
Variants & pricing
Drive Unit – Wave Machine
1021156€462.00
