Chemistry equipment
Melting Point Apparatus Eyepiece Camera
This eyepiece camera digitally captures the melting process during melting-point determination. It records the process alongside temperature data.
Specifications
- Brand
- PASCO · SE-6215
- Active Sensor Area
- 3.84 x 2.16 mm
- Resolution
- 1 MP (1280 x 720)
- Pixel Size
- 3.0 µm x 3.0 µm
- Native format
- mjpg
- Connection protocol
- UVC
- Sensor Type
- CMOS
- Shutter
- Electronic Rolling Shutter
- Frame Rate
- 25 fps
- Mount size (diameter)
- 23 mm
- Device height
- 40 mm
- Compensating lens
- none
- Connectivity
- USB 2.0
- Power
- 5v / 200 mA
- Operating Temperature Range
- -10 - 50 °C
- Humidity
- 30 - 80 %
On request
Variants & pricing
Melting Point Apparatus Eyepiece Camera
SE-6215On request
