Pirani Vacuum Gauge for Fine and Rough Vacuum Control
Programmable benchtop instrument for measuring and controlling fine and rough vacuum with a Pirani gauge. It includes a membrane keypad, 2.5 m measuring line and mains cable, with a measuring range of 1100–0.001 hPa.
Specifications
- Brand
- 3B Scientific · 1012514
- Vacuum connection
- DN 16 KF
- Measuring range
- 1100 – 0.001 hPa
- Measurement uncertainty
- < 20% of the display value
- Display
- Digital LED display in mbar, Pa, psi, torr
- Digit height
- 10 mm
- Readout
- 5 per s
- Threshold switch
- 2 x 230 V, 2 A, independently adjustable
- Switching accuracy/hysteresis
- ± 1 digit
- Permissible overload
- 2 bar absolute
- Power consumption
- max. 15 W
- Supply voltage
- 100 / 115 / 230 V, 50/60 Hz
- Dimensions
- 90 mm x 120 mm x 90 mm approx.
- Weight
- 0.9 kg approx.
from
€2,367.00
Variants & pricing
Pirani Vacuum Gauge for Fine and Rough Vacuum Control
1012514€2,367.00
