Experiment kits & teaching aids

SEK Optics 1, Halogen 20 W (02)

Student experiment kit on optics with a 20 W halogen optics lamp. Supplied in a storage box with a fitted insert.

Included in the kit:

  • 1× Optics Lamp 2, SE, 20 W Halogen (P5111-1L)
  • 1× Shutter 02, SE, 1 + 2 Slits (P5111-2A)
  • 1× Shutter 02, SE, 3 + 5 Slits (P5111-2B)
  • 1× Shutter 02, SE, Circular Aperture (P5111-2E)
  • 1× Shutter 02, SE, Solid Cover (P5111-2F)
  • 1× Acrylic Lens Body, Semicircular, SE (P5520-1A)
  • 1× Acrylic Lens Body, Parallel and Trapezoidal, SE (P5520-1F)
  • 1× Acrylic Right-Angle Prism Body, SE (P5520-1E)
  • 2× Acrylic Lens Body, Plano-Convex, SE (P5520-1B)
  • 1× Acrylic Lens Body, Plano-Concave, SE (P5520-1C)
  • 1× Optical Disc with Scale, SE (P5620-1A)
  • 1× White Screen, SE (P5610-5C)
  • 1× Plane Mirror on Block (P5600-5A)
  • 1× Adjustable Concave/Convex Mirror (P5600-5B)
  • 1× Hollow Plastic Tank (P5710-1B)
  • 1× Optics 1 Box Insert, SE (P7906-5G)
  • 1× Small storage box II, with lid (P7806-1K)

Experiments you can carry out:

  • OPS 1.1 Light propagates rectilinearly
  • OPS 1.2 Shadow
  • OPS 2.1 Reflection on a plane mirror
  • OPS 2.2 Images on a plane mirror
  • OPS 2.3 Reflection on a concave mirror
  • OPS 2.4 Construction of images for a concave mirror
  • OPS 2.5 Image of a point by means of a concave mirror
  • OPS 2.6 Reflection on a convex mirror
  • OPS 2.7 Construction of images for a convex mirror
  • OPS 2.8 Image of a point by means of a convex mirror
  • OPS 3.1 Refraction on a plane-parallel body
  • OPS 3.2 Refraction coefficient of glass
  • OPS 3.3 Refraction at transition from air into water
  • OPS 3.4 Angle of incidence and angle of refraction
  • OPS 3.4.1 Index of refraction of solid matters
  • OPS 3.4.2 Calculation of the parallel displacement of the plane-parallel body
  • OPS 3.5 The transition from glass into air
  • OPS 3.6 Deviating and the reversing prism
  • OPS 3.7 Refraction at a prism
  • OPS 4.1 Refraction at convex lenses
  • OPS 4.2 Marginal rays
  • OPS 4.3 Construction of images by means of a convex lens
  • OPS 4.4 Image of a point by means of a convex lens
  • OPS 4.5 Refraction at a concave lens
  • OPS 4.6 Construction of images by means of a concave lens
  • OPS 4.7 Image of a point by means of a concave lens
  • OPS 5.1 Color dispersion
  • OPS 6.1 The normal sighted eye
  • OPS 6.2 Short-sightedness
  • OPS 6.3 Far-sightedness
  • OPS 6.4 Presbyopia

Specifications

Brand
NTL · P9902-4L

from

€210.00

All options (1)

Variants & pricing

  • SEK Optics 1, Halogen 20 W (02)

    P9902-4L€210.00
