Heating, drying & sterilisation
Drying / Heating Oven SWOV, Vacuum Oven, SmartLab, 19/30/70 L, 200°C, 10750 mmHg
The SWOV is a SmartLab vacuum drying oven for drying, baking, conditioning, curing, degassing of solids and liquids, vacuum embedding, humidity testing, plating and ageing tests. It offers simple evacuation and venting with an easy-to-read vacuum gauge, a heat-resistant moulded silicone door seal, and a safety window in tempered safety glass 12T and polycarbonate 5T. The interior is stainless steel with a powder-coated steel housing and glass-wool insulation.
Specifications
- Brand
- Witeg · DH.SWOV03020 +2
- Evacuation / venting
- Simple evacuation and venting, easy-to-read vacuum gauge
- Door seal
- Heat-resistant moulded silicone seal
- Safety window
- Tempered safety glass 12T & polycarbonate 5T
- Interior
- Stainless steel
- Housing / insulation
- Powder-coated steel housing, glass-wool insulation
- Shelves
- 2x aluminium shelves included
- Recommended vacuum pump
- Rocker 810 (18.6 L & 30 L ovens); Rocker 800 / Rocker 811 (70 L oven)
- Controller
- Smart-Lab™ controller with 4″ TFT LCD touchscreen
- Connectivity
- WiRe™ app service, remote control, USB data transfer, Wi-Fi
- Certification
- CE & UL/CUL, serial-number traceability
from
€4,547.00
Variants & pricing
Drying / Heating Oven SWOV, Vacuum Oven, SmartLab, 19/30/70 L, 200°C, 10750 mmHg
DH.SWOV03020€4,547.00Drying / Heating Oven SWOV, Vacuum Oven, SmartLab, 19/30/70 L, 200°C, 10750 mmHg
DH.SWOV03030€4,692.00Drying / Heating Oven SWOV, Vacuum Oven, SmartLab, 19/30/70 L, 200°C, 10750 mmHg
DH.SWOV03070€5,627.00
