Power supplies & measuring instruments
Smart multimeter, 600 V AC/DC, NCV and LIVE test, P 1072
Compact True RMS multimeter for up to 600 V AC/DC, certified CAT III. NCV provides non-contact voltage detection; LIVE identifies phase and neutral conductors. Automatic function recognition eliminates the rotary selector. The 4000-count LCD has blue backlighting that turns red when ranges are exceeded or NCV detects voltage. Measures voltage, resistance, temperature, capacitance and frequency, with continuity and diode tests.
Also listed in: Education: Power supplies & measuring instruments
Specifications
- Brand
- PeakTech · P 1072
- Auto-Scan
- Yes
- Basic Accuracy DC
- ± 0,5 %
- Battery
- 1,5 V AAA
- Capacitance max.
- 1 mF
- Display counts
- 4 000
- Display Type
- LCD
- LED-lamp
- Yes
- NCV
- Yes
- Over voltage category
- CAT III 600 V
- Range selection
- Automatic
- True RMS
- Yes
- V DC max.
- 600 V
- Hz max.
- 4 kHz
- OHM max.
- 40 MΩ
- Temp. max.
- 1200 °C
- Temp. min.
- -200 °C
- V AC max.
- 600 V
from
€19.00
Variants & pricing
Smart multimeter, 600 V AC/DC, NCV and LIVE test, P 1072
P 1072€19.00
